550 Walk Up Service Window
550 Walk Up Service Window

    550 Walk Up Service Window

    The 550 window features two service openings in one window. There is a fixed center pane with two independently operating panels that slide toward the center. Smoothly and easily opens and closes on overhead rollers, which makes for a track-free sill that is easy to keep clean. Perfect for use as a concession window or food truck window. Also popular for interior office, pharmacy, or convenience store applications.

    Anodized aluminum extrusions and ¼” tempered glass combine to give you an attractive, functional, affordable transaction window that will not rust, pit or weather. Track free bottom sill provides for a contaminant free serving surface. Bottom sill is angled downward to ensure rain, sleet and snow are deflected away from the interior. The 550 is so simple to operate. The service door slides open effortlessly then automatically slide shut and self latches every time it closes so it cannot be pushed open form the outside. Also includes a thumb turn lock and night locking bar.

    • Fully assembled, pre-glazed and ready to install
    • Dark Bronze or Clear (silver) frame

    APPLICATIONS

    • Restaurants
    • Ticket Windows
    • Teller Windows
    • Restaurant Walk Up
    • Concession Windows
    • Convenience Store
    • Dispensary
    • Distribution Center
    • Guard Shack
    • Liquor Store
    • Medical Office/Hospital
    • Office Reception
    • Park / Zoo
    • Parking Garage
    • Pharmacy Interior
    • Scale House
    • School
    • Park Districts
    • Stadiums
    Specifikim
    • STANDARD FEATURES

      Standard Sizes:

      • 95.5″w x 35.75″h x 4″d (19″w x 27.25″h service opening)
      • 84″wx 35.75″h x 4″d (17″w x 27.25″h service opening)
      • Customizable – Restrictions may apply

      Standard Glazing:

      • ¼” Clear Tempered Glazing

      Available Operating Systems:

      • (SC) Manual Open / Self Close
      • Manual Open / Manual Close – By request

      CUSTOM OPTIONS

      • Custom Frame Size
      • Custom Transoms
        – Solid Glass
        – Split to house AA100 Fly Fans
      • Custom Glazing
          • – Tint
          • – Low E Hard Coat
          • – 5/16 Laminated Safety Glass
      • Powder Coated Frame – specify RAL from Tiger Drylac
    Specifikime teknike
    • Referencë unike550-series-service-window
    • Familja e produkteveWindows
    • Grupi i produkteveWalk Up Windows
    • LlojiObjekt (një objekt të vetëm)
    • Data e botimit2022-08-30
    • Numri i botimit1
    Të ngjashme
    • Projektuar nëShtetet e Bashkuara
    • Prodhuar nëShtetet e Bashkuara
    Klasifikimi
    • Kategoria BIMobjectDritare - Hapje kursor
    • IFC classificationDritare
    • Emrin UNSPSCWindows
    • UNSPSC code301716
    • Uniclass 2015 CodePr_30_59_57
    • Uniclass 2015 PërshkrimOpening security and protection products
    • CSI MasterFormat 2014 Code08 56 53
    • CSI MasterFormat 2014 TitleSecurity Windows
    • OmniClass Number23-17 13 29
    • OmniClass TitleSecurity Windows
    • CSI UniFormat II CodeB2020
    • CSI UniFormat II TitleExterior Windows
