275 Low Profile Single Panel Sliding Transaction Window
275 Low Profile Single Panel Sliding Transaction Window

    275 Low Profile Single Panel Sliding Transaction Window

    4.8 out of 5 stars4.8(6 reviews)

    The 275 Low Profile transaction window has the same overall frame size as the 275 with a smaller header for more glass, less metal. The low profile header makes this unit ideal for use as a sliding reception window, interior pharmacy window, or office pass through window. Smoothly opens with just a finger or two on the handle. Self-closing operating system is located in the header for a track-free service area.

    Anodized aluminum extrusions and ¼” tempered glass combine to give you an attractive, functional, affordable transaction window that will not rust, pit or weather. Track free bottom sill provides for a contaminant free serving surface. Bottom sill is angled downward to ensure rain, sleet and snow are deflected away from the interior. Self latches every time it closes so it cannot be pushed open from the outside. Also includes a thumb turn lock and night locking bar.

    • Fully assembled, pre-glazed and ready to install
    • Dark Bronze or Clear (silver) frame
    • Specify L/R or R/L slide direction from outside view

    APPLICATIONS

    • Restaurants
    • Interior Transaction Windows
    • Ticket Windows
    • Teller Windows
    • Foodservice projects
    • Restaurant Drive Thru
    • Restaurant Walk Up
    • California Health Code Compliant (when restricted opening / air curtain selected)
    • Concession Windows
    • Food Truck
    • Bank
    • Car Wash
    • Convenience Store
    • Dispensary
    • Distribution Center – Amazon
    • Guard Shack
    • Liquor Store
    • Medical Office/Hospital
    • Office Reception
    • Park / Zoo
    • Parking Garage
    • Pharmacy Interior
    • Scale House
    • School
    • Stadium
    • Theater
    Specifikim
    • STANDARD FEATURES

      Standard Sizes:

      • 47.5”w x 43.5”h x 4”d (19”w x 39”h service opening)
      • 47.5”w x 35.75”h x 4”d (19”w x 31.25”h service opening)
      • 35.75”w x 35.75”h x 4”d (13.5”w x 31.25”h service opening)*
      • Customizable – Restrictions may apply

      *Meets CA restricted service opening requirement – under 432 square inches

      Standard Glazing:

      • ¼” Clear Tempered Glazing

      Available Operating Systems:

      • (SC) Manual Open / Self Close adjustable to manual open/manual close
      • (MOER) Manual Open / Electronic Release –electromagnetic hold-open device with presence sensor

      CUSTOM OPTIONS

      There are many ways to customize the 275 Low Profile to suit your project.

      • Custom Frame Size
      • Custom Glazing
        – Tint
        – Low E Hard Coat
        – 5/16 Laminated Safety Glass
      • Powder Coated Frame – specify RAL from Tiger Drylac
    Specifikime teknike
    • Referencë unike275-low-profile-single-transaction-window
    • Familja e produkteveWindows
    • Grupi i produkteveTransaction Windows
    • LlojiObjekt (një objekt të vetëm)
    • Data e botimit2022-08-30
    • Numri i botimit1
    Të ngjashme
    • Projektuar nëShtetet e Bashkuara
    • Prodhuar nëShtetet e Bashkuara
    Klasifikimi
    • Kategoria BIMobjectDritare - Hapje kursor
    • IFC classificationDritare
    • Emrin UNSPSCWindows
    • UNSPSC code301716
    • Uniclass 2015 CodePr_30_59_57
    • Uniclass 2015 PërshkrimOpening security and protection products
    • CSI MasterFormat 2014 Code08 56 53
    • CSI MasterFormat 2014 TitleSecurity Windows
    • OmniClass Number23-17 13 29
    • OmniClass TitleSecurity Windows
    • CSI UniFormat II CodeB2020
    • CSI UniFormat II TitleExterior Windows
