GUSTO SINK MIXER C ROUND SPOUT BLUE START

GUSTO SINK MIXER C ROUND SPOUT BLUE START

GUSTO SINK MIXER C ROUND SPOUT BLUE START

GUSTO SINK MIXER C ROUND SPOUT BLUE START

GUSTO SINK MIXER C ROUND SPOUT BLUE START

GUSTO SINK MIXER C ROUND SPOUT BLUE START

GUSTO SINK MIXER C ROUND SPOUT BLUE START

Single lever sink mixer rim- mounted with C fixed round spout Blue Start

规格

Single lever sink mixer rim- mounted with C round spout, Blue Start, FirmaFlow cartridge with diameter 28mm with hot water limiter, Cylindrical Brass body with diameter 37mm and Blue Start red and blue color indication, Metal handle, C round tubular spout with diameter 20mm and aerator CACHE M16,5x1A with flow rate limiter 5lpm, Regular aerator in a separate bag in the packaging, Swivel range of the spout 360°, 2 pieces of PEX flexible hoses G3/8 and length 425mm, Fixation- Easy Fix + for kichen mixers finish.

技术规格

唯一参考BD546
产品系列Gusto
产品组Taps & Mixers
类型对象（单个对象）
发布日期2023-08-01
版本号1
高度 (mm)72
宽度 (mm)305
深度 (mm)715

链接

相关

主材料黄铜
净重 (Kg)1.62

分类

BIMobject 类别卫生 - 龙头/水龙头/铜器
IFC 分类卫浴终端
ETIM 代码EC011431
ETIM 名称Kitchen mixing tap
UNSPSC 名称Sanitary ware
UNSPSC 代码301815
Uniclass 2015 代码Pr_40_20_87_82
Uniclass 2015 说明Sink manual water supply sets
OmniClass 编号23-31 11 00
OmniClass 标题Faucets

发售地区

亚洲	非洲
也门	埃及
以色列
伊拉克
伊朗
卡塔尔
叙利亚
土耳其
巴勒斯坦
巴林
沙特阿拉伯
科威特
约旦
阿富汗
阿拉伯联合酋长国
阿曼
黎巴嫩
