Sphera Element homogeneous vinyl
Sphera Element homogeneous vinyl
Sphera Element homogeneous vinyl
Sphera Element homogeneous vinyl

    Sphera Element homogeneous vinyl

    The widest and most complete colour offer in homogeneous vinyl
    Sphera Element has the most complete colour proposition in the market and its subtle design is ideal for use in areas where the floor is required to blend in with the environment. Sphera Element is used in a wide variety of applications, including specific areas in healthcare and industrial environments.

    The Element colour palette consists of 52 colours. The carefully selected outspoken pastels and bright accent colours are ideal for areas requiring zoning or to create an authentic and welcoming interior. The 9 Contrast designs have a more pronounced pattern and a higher contrast between the three colour components.

    • Many colours with high LRV values
    • Excellent dirt hiding and scratch resistant properties
    • Approved for use in cleanrooms up to ISO class 4
    • Perfect solution for care and cure spaces, public buildings and education facilities

    规格
    • Roll width: 200 cm
      Roll length: ≤ 27 m
      Surface finish: SMART top
      Binder content: type 1
      Classification domestic use (EN ISO 10874): class 23
      Classification commercial use (EN ISO 10874): class 34
      Classification light industrial use (EN ISO 10874): class 43
      Total thickness: 2.0 mm
      Total weight: 2900 g/m²
      Dimensional stability (EN ISO 23999): ≤ 0.4%, typical value ~ 0.2%
      Slip resistance (DIN 51130): R9
      Residual indentation (EN ISO 24343-1): ≤ 0.10 mm, typical value ~ 0.03 mm
      Castor chair continuous use (ISO 4918): pass
      Colour fastness to light (ISO 105-B02): ≥ 7
      Indoor air emissions: TVOC after 28 days (EN 16516): ≤ 0.01 mg/m3
      Resistance to chemicals (EN ISO 26987): very good
      Flexibility (EN ISO 24344): Ø 10 mm
      Use in wet areas (EN 13553): yes
      Bacteria resistance (EN ISO 846): does not support growth
      Cleanroom particle emission (ISO 14644-1): ISO 4

      Reaction to fire (EN 13501-1): Bfl-s1, L, CS
      Slip resistance (EN 13893): μ ≥ 0.30
      Body voltage (EN 1815): ≤ 2 kV
      Thermal conductivity (EN 12524): 0.25 W/mK

      All Forbo Flooring Systems’ sales organisations worldwide have a certified Quality Management System in accordance with ISO 9001.
      All Forbo Flooring Systems’ manufacturing operations have a certified Environmental Management System in accordance with ISO 14001.
      The Life Cycle Assessment (LCA) of Forbo Flooring Systems’ products is documented in individual Environmental Product Declarations (EPD’s) which can be found on all of our websites.

    技术规格
    • 唯一参考sphera-element
    • 产品系列Flooring
    • 产品组Homogeneous Vinyl
    • 类型对象(单个对象)
    • 发布日期2022-01-28
    • 版本号1
    • 高度 (mm)27000
    • 宽度 (mm)2000
    • 深度 (mm)2
    相关
    • 主材料乙烯基
    • 设计国家/地区荷兰
    • 制造国家/地区荷兰
    • 净重 (Kg)2.9
    分类
    • BIMobject 类别地板 - Vinyl
    • IFC 分类Floor
    • UNSPSC 名称Vinyl flooring
    • UNSPSC 代码30161707
    • Uniclass 2015 代码EF_30_20
    • Uniclass 2015 说明Floors
    • CSI MasterFormat 2014 代码09 60 00
    • CSI MasterFormat 2014 标题Flooring
    • OmniClass 编号23-15 17 00
    • OmniClass 标题Floor Coverings
    • CSI UniFormat II 代码C3020
    • CSI UniFormat II 标题Floor Finishes
