Heritage conservation roof window, top-hung GCL
Heritage conservation roof window, top-hung GCL
Heritage conservation roof window, top-hung GCL
Heritage conservation roof window, top-hung GCL
Heritage conservation roof window, top-hung GCL
Heritage conservation roof window, top-hung GCL
Heritage conservation roof window, top-hung GCL
Heritage conservation roof window, top-hung GCL
Heritage conservation roof window, top-hung GCL
    VELUX roof windows

    Heritage conservation roof window, top-hung GCL

    4.6 out of 5 stars4.6(12 reviews)

    The VELUX Conservation roof window is designed to be in-keeping with historical façade aesthetics. Slim and elegant and sitting flush to the tiles, it blends beautifully into historical roofs.
    Conservation roof window GCL is top-hung, has a black exterior and is operated with a winding handle fixed to the bottom frame. The window is designed to blend into buildings in conservation areas and installed in the roof using a VELUX flashing made of black aluminum.

    • Frame and sash made of laminated pine wood and are white finished with triple coat.
    • The exterior of the sash is metal-clad and therefore maintenance-free.
    • The window is equipped with an insulating glass unit.



        Window
        Sizes:
        External frame
        W x H mm:
        Effective daylight
        areas: m²
        CC04550 x 9780.33
        CC06550 x 11780.42
        FC06660 x 1178
        0.53
        FC08660 x 1398
        0.64
        MC06
        780 x 1178
        0.65
        MC08780 x 1398
        0.79
        PC08942 x 1398
        0.99
        SC08
        1140 x 1398
        1.23
        SC101140 x 1600
        1.43



        VELUX roofwindows roofwindow roof windows roof window skylight skylights heritage conservation

        Специфікація
        • Finishes:

          Internal

          • Pine wood, finished with triple coat, white-painted.

            External –
          • Black Aluminium .
        Технічна специфікація
        • Унікальний номерGCL
        • Сімейство продуктівConservation
        • Група продуктівManual bottom operated
        • ТипObject (single object)
        • Дата публікації2025-01-21
        • Номер видання1
        Пов'язані
        • Матеріал основнийPine
        • Матеріал допоміжнийGlass
        Класифікація
        • Категорія BIMobjectВікно - Слухове вікно
        • Класифікація IFCWindow
        • Назва UNSPSCRoofing accessories
        • Код UNSPSC301516
        • Код Uniclass 2015Ss_30_30_72_73
        • Опис Uniclass 2015Roof window systems
        • Код CSI MasterFormat 201408 61 00
        • Заголовок CSI MasterFormat 2014Roof Windows
        • Номер OmniClass23-17 13 23
        • Заголовок OmniClassRoof Windows
        • Код CSI UniFormat IIB3020
        • Заголовок CSI UniFormat IIRoof Openings

        Доступність регіону

        Європа
        Croatia
        France
        United Kingdom
