CH PIR cold store sandwich panel

The ARPANEL CH PIR cold store sandwich panels with polyisocyanurate foam core offer excellent thermal performance to ensure thermal insulation of walls. The cold store sandwich panels guarantee excellent tightness of the room. The properties of the PIR core and its combination with the facings give the panels very high mechanical strength. The cold store sandwich panels should be installed at the inner side of the structure. This ensured proper and longest possible functioning of the facility, with the lowest possible energy consumption.

Specifikim

Thickness [mm]	120	140	160	200
Fastening system	Standard	Standard	Standard	Standard
Insulation core	Polyisocyanurate foam PIR	Polyisocyanurate foam PIR	Polyisocyanurate foam PIR	Polyisocyanurate foam PIR
Panel width [mm]	1000/1100/1150	1000/1100/1150	1000/1100/1150	1000/1100/1150
Available length [m]	2 – 18,5	2 – 18,5	2 – 18,5	2 – 18,5
Thickness of ext. facing [mm]	0,5-0,7	0,5-0,7	0,5-0,7	0,5-0,7
Thickness of int. facing [mm]	0,4-0,7	0,4-0,7	0,4-0,7	0,4-0,7
Core density kg/m3	40 ± 3	40 ± 3	40 ± 3	40 ± 3
Weight kg/m2	12,6	13,4	14,2	15,7
Heat-transfer coefficient Ud,S = W/(m2 x K) *for 0°C	0,17	0,15	0,13	0,1
Fire resistance:
Acc. to PN-B-02867	NRO	NRO	NRO	NRO
Acc. to PN-EN 13501-1	B- s1,d0	B- s1,d0	B- s1,d0	B- s1,d0
Acc. to PN-EN 13501-2 VERTICAL	E 30/EI 30	E 30/EI 30	E 30/EI 30	E 60/EI 45/EW 60
Acc. to PN-EN 13501-1 HORIZONTAL	E 30/EI 30/EW 30	E 30/EI 30/EW 30	E 30/EI 30/EW 30	E 45/EI 45/EW 45
Acc. to PN-EN 13501-5	Not applicable	Not applicable	Not applicable	Not applicable
Proper acoustic insulation [Rw(C,Ctr) dB]	24 (-2;-4)	24 (-2;-4)	24 (-2;-4)	24 (-2;-4)
Sound absorption [αw]	0,15	0,15	0,15	0,15

Specifikime teknike

Referencë unikech-pir-cold-store-sandwich-panel
Familja e produkteveSandwich panels
Grupi i produkteveCold store sandwich panels
LlojiMaterial për ndërtim
Data e botimit2023-08-04
Numri i botimit1

Lidhje

Product URLhttps://arpanel.eu/products/pir/cold-store/
Përshkrimet teknikehttps://arpanel.eu/wp-content/uploads/2023/06/DWU_CH_PIR_EN.pdf

Të ngjashme

Materiali kryesorPIR polyisocyanurate
Materiali dytësorÇelik
Projektuar nëPoloni
Prodhuar nëPoloni

Klasifikimi

Kategoria BIMobjectMuret - Kolegjet sanduiç
IFC classificationMur
Kodi ETIMEC011925
Emri ETIMSandwich panel
Uniclass 2015 CodeSs_20_10_60_84
Uniclass 2015 PërshkrimStructural insulated panel systems
OmniClass Number23-19 31 19 13 11
OmniClass TitleCold Storage Rooms
