Ultrasonic Flow Sensor, ULTRAFLOW® 54, DN 100 x 360 mm

Ultrasonic Flow Sensor, ULTRAFLOW® 54, DN 100 x 360 mm

Kamstrup’s heat and cooling meters are based on a deep understanding of the challenges faced by customers. Combined with decades of experience developing innovative ultrasonic technology and future-proof design, the result is high-quality meters with simpleto-use functionality, unrivalled accuracy and reliability. Kamstrup is a world-leading supplier of intelligent energy and water metering solutions. At Kamstrup, we define success by the progress we create for others. Our superior technology and expertise have been the foundation from which to transform businesses and markets, by creating more efficient ways of working, ever since the company was founded by Olaf Kamstrup in Denmark in 1946.

Specifikim

ULTRAFLOW® 54 is a static flow sensor based on the ultrasonic measuring principle. It is used as a volume flow rate sensor primarily for energy meters such as MULTICAL®. ULTRAFLOW® 54 has been designed for use in heating installations where water is the heat-bearing medium. ULTRAFLOW® 54 is type approved for the mechanical environment M2 and with a larger dynamic range as well as a reduced pressure loss. ULTRAFLOW® 54 employs micro-processor technology and ultrasonic measuring techniques. All circuits for calculating and measuring are collected on a single board, providing compact and rational design in addition to an exceptionally high level of measuring accuracy and reliability. The flow is measured using bidirectional ultrasonic technique based on the transit time method, with proven long-term stability and accuracy.

Specifikime teknike

Referencë unike65-5-FACL-XXX
Familja e produkteveHeat/Cooling meters
Grupi i produkteveULTRAFLOW® 54
LlojiObjekt (një objekt të vetëm)
Data e botimit2019-11-22
Numri i botimit1
Gjatësia (mm)220
Gjerësia (mm)360
Thellësia (mm)220

Lidhje

Product URLhttps://www.kamstrup.com/en-en/heat-solutions/heat-meters/ultraflow
Udhezime instalimihttps://products.kamstrup.com/?goto=178-28
Përshkrimet teknikehttps://products.kamstrup.com/?goto=178-31

Të ngjashme

Materiali kryesorÇelik
Materiali dytësorPlastik
Projektuar nëDanimarkë
Prodhuar nëDanimarkë
Weight Net (kg)21.7

Klasifikimi

Kategoria BIMobjectPajisje hidraulike - Të tjera
IFC classificationSegmenti i rrjedhës
Kodi ETIMEG000045
Emri ETIMMeters
Emrin UNSPSCMetering or injection or proportioning pumps
UNSPSC code40151552
Uniclass 2015 CodePr_80_51_46_92
Uniclass 2015 PërshkrimUltrasonic flowmeters
CSI MasterFormat 2014 Code40 71 76
CSI MasterFormat 2014 TitleThermal Flow Meters
OmniClass Number23-27 15 17
OmniClass TitleEnergy Monitoring and Controls
