TransTrax Banking Carrier

Reliability is the hallmark of the TransTrax remote lane carrier for banking drive-thru. TransTrax runs on a positive-drive tape system that only requires four moving parts, minimizing the need (and cost) for maintenance. It includes a solid-state electronics logic control system, as well as 1-on-1 audio. The carrier box itself is not affected by leaks or condensation, meaning financial documents and other paperwork are safe from the elements.

Specifikim

Ratings	UL-listed
Materials used	Aluminum tube/track; Aluminum & Plastic carrier
Finish options	Not available
Unit height (range)	9' 5-3/4" - 16' to top of horizontal tube
Unit max extension/horizontal run	60 ft. at 16 ft. elevation
Track configurations	Standard, Splayed, Reverse Lane
Carrier dimensions / capacity	1-3/8" L x 4-1/4" W x 10" H 1 lb max weight load
Required clearances (wall openings, overhang)	12"x12" horizontal clear channel, 12"x12" wall opening, 12"x12" ceiling opening, 6" rec. counter clearance (vertical) for control box
Power requirements	110V, PH.1, 20 AMP circuit; interior outlet
Motor	90V DC
Controls	Teller: Power, Car, Truck, Recall, Audio; Customer: Send, Help
Product options	Exterior TransTrax skin (stainless steel), customer control box button alignment (left or right), video, audio, vehicle detectors, lane lights
Audio included	BavSonic duplex audio

Specifikime teknike

Referencë unikeTransTrax_Banking_Carrier
Familja e produkteveRemote Lane Carriers
Grupi i produkteveBanking Carrier
LlojiObjekt (një objekt të vetëm)
Data e botimit2024-11-07
Numri i botimit1

Lidhje

Product URLhttps://www.bavis.com/transtrax-basic-carrier

Klasifikimi

Kategoria BIMobjectInxhinieri & Infrastrukturë - Sistemet Drive-through
