Modsorbor™ Sound Absorption Panel

The Modsorbor™ Panel consists of a high performance low frequency tuned acoustical core with hardened square or shaped edges and wrapped in an acoustical fabric. The Modsorbor™ Panel offers durability and focused low frequency absorption without affecting other frequencies, yielding an NRC as low as 0.30.

Features

Cost-effective solution for efficient sound absorption, control and excess reverberation.
Available in custom sizes up to 4′ W x 10′ L and 1”,2”, 3” or 4” T.
Select from industry standard and custom fabrics, fabrics with proof of performance acoustical data preferred.
Hardened edge termination options include square, miter, radius and bevel.
Lightweight and easy to install with RPG’s Impalit™ clip.
All components Class A Fire Rated.

Spesifikasjon

Finish - Wrapped with RPG reviewed industry standard and custom fabrics. Fabrics with acoustical performance data are preferred.
Product Material Composition - Fabric
Product Acoustic Function - Low Frequency/Bass Mgt.
Product Core Fire Rating - All Class A Components
Weight PSF - 1.00
Installation - Modsorbor™ Panels can be easily and quickly hung on any wall surface using RPG’s Impalit clip. For ceiling applications, the panels can be either direct mounted with Z-bar attachments or suspended using a cloud anchor kit. Panels can also be configured to install in a standard T-bar grid.

Tekniske spesifikasjoner

Unik ref.modsorbor
ProduktfamilieArchitectural Acoustics
ProduktgruppeLow Frequency/Bass Mgt.
TypeObjekt (enkelt objekt)
Utgivelsesdato2024-01-31
Utgavenummer1

Lenker

Produktets nettadressehttps://www.rpgacoustic.com/product/modsorbor/
Monteringsanvisninghttps://www.rpgacoustic.com/product/modsorbor/#resources-section
Produktsertifiseringhttps://www.rpgacoustic.com/product/modsorbor/#resources-section
Teknisk beskrivelsehttps://www.rpgacoustic.com/wp-content/uploads/2022/09/Modsorbor-Panel-Data-Sheet.pdf

Relatert

Hovedmaterialetekstil
Designet iUSA
Produsert iUSA

Klassifisering

BIMobject kategoriByggematerialer - Akustiske Plater og tilbehør
IFC-klassifiseringmøblerings del
ETIM-kodeEG017960
ETIM-navnFurniture
Uniclass 2015 kodeSs_25_25_05
Uniclass 2015 beskrivelseAcoustic panel systems
CSI MasterFormat 2014 kode09 84 00
CSI MasterFormat 2014 tittelAcoustic Room Components
OmniClass-nummer23-15 13 19 35
OmniClass-tittelAcoustical Wall Treatment
