Global System Sp. Z o.o.

FIRE CURTAINS EI90, EI120 AUTOMATIC

GSF KPR Fire-Rated Roller Shutter by GLOBAL SYSTEM is intended for closing off opening in vertical partitions, both internal and external. The main purpose of the shutter is to limit the spread of fire and the flow of gases and heat for 90-120 minutes. Shutters separate fire zones in buildings and enable safe evacuation. They can be applied in public facilities and in other types of buildings. GSF KPR EI shutter by GLOBAL SYSTEM is equipped with an electric drive - a tubular motor, usually located on the right side.

Spesifikasjon

TYPES OF FIRE-CURTAINS
Classified by control system
- GSF KPR EI Fire Curtain with electric drive
- GSF KPR EI Fire Curtain with fusible link
Classified by fire resistance class
- EI120
- EI90
- EI60
- EI45
- EI30
- EI15
FIRE CURTAIN COMPONENTS
GSF KPR EI Fire Curtains consist of
- Curtain
- System of guide rails
- Rolling shaft
- Curtain housing box
- Bottom bar
- Tubular motor or fusible link
The curtain - made of fire-resistant material – is rolled up around a shaft and maintained in this position. The shutter is controlled via
- Electric drive – it can be integrated with the fire alarm system
- Fusible link – in the event of fire the fusible link will release the shutter at ca. 70°C and the shutter will close by gravitational force.
OPTIONAL FEATURES
- Painting guide rails and the housing box any colour from the RAL colour chart
ADVANTAGES
- Only one light layer of ULFFG curtain
- Significant reduction in mass – lower load-bearing capacity requirements, easier to install
- Less space required – compact-sized curtain and gate
- Competitive price

Tekniske spesifikasjoner

Unik ref.fire-curtains-ei90-ei120-automatic
TypeObjekt (enkelt objekt)
Utgivelsesdato2022-07-05
Utgavenummer1
Høyde (mm)6300
Bredde (mm)10000

Lenker

Produktets nettadressehttp://en.globalsystem.com.pl/produkt/gsf-kpr-ei-fire-curtains.html
Teknisk beskrivelsehttps://globalsystem.com.pl/admin-inf/wp-content/uploads/2020/02/EN_GSF-KPR-EI90EI120-3.pdf

Relatert

Designet iPolen
Produsert iPolen

Klassifisering

BIMobject kategoriDører - Branndører og -skodder
IFC-klassifiseringBygningselement
