H96251BEL SECURITHERM BIOCLIP thermostatic sink mixer
H96251BEL SECURITHERM BIOCLIP thermostatic sink mixer
    DELABIE

    H96251BEL SECURITHERM BIOCLIP thermostatic sink mixer

    Deck-mounted thermostatic SECURITHERM sink mixer. Sequential thermostatic mixer: opens and closes with cold water. No risk of cross flow between the hot and cold water. No non-return valves on the inlets. BIOCLIP: mixer is easy to remove for cleaning and disinfection. Anti-scalding failsafe: shuts off automatically if cold or hot water supply fails. Securitouch thermal insulation prevents burns. Single hole mixer with curved spout H. 160mm L. 140mm fitted with a hygienic flow straightener with no impurity retention and thermal shock-resistant. Scale-resistant sequential thermostatic cartridge for single control of flow rate and temperature. Temperature adjusts from cold water up to 40°C with temperature limiter set at 40°C. Thermal and chemical shocks are possible. Body and spout with smooth interiors and low water volume. Flow rate 9 lpm at 3 bar. No manual contact thanks to Hygiene control lever L. 146mm. No pop-up waste. F3/8" PEX flexibles with filters and non-return valve on the CW inlet. Fixing reinforced by 2 stainless steel rods. Thermostatic mixer ideal for healthcare facilities, retirement and care homes, hospitals and clinics. Sequential mixer suitable for people with reduced mobility. 30-year warranty. Also available with copper tails.
    기술 사양
    • 특징 참조H96251BEL
    • 제품군Sanitary
    • 제품분류Sink mixer
    • 유형개체 (단일 개체)
    • 게시일2025-06-05
    • 에디션 넘버1
    • 높이(mm)273
    • 너비(mm)50
    • 깊이(mm)178
    관련성
    • 주 재료놋쇠
    • 설계국가프랑스
    • 제조국가프랑스
    • 순 중량(Kg)2.19
    분류
    • BIMobject 카테고리위생 - 수도꼭지
    • IFC 분류위생 터미널
    • ETIM 코드EC011328
    • ETIM 이름Washbasin mixing tap
    • Uniclass 2015 코드Pr_40_20
    • Uniclass 2015 설명Sanitary fittings and accessories
    • CSI 마스터 형식 2014 코드41 14 33
    • CSI 마스터 형식 2014 제목Mixers
    • OmniClass 번호23-31 11 19 11
    • OmniClass 제목Thermostatically Controlled Faucet Mixing Valves

    지역 가용성

    유럽
    네덜란드
    뤽상부르
    벨기에
