MAC Ultra Performance, 1150 W High Output LED Moving Head Profile with Framing

FEATURES

LIGHT SOURCE

• 1150 W proprietary LED light engine
• 84 x 20 W white LEDs
• Minimum LED lifetime: >50,000 hours (see specs for further details)

PHOTOMETRIC DATA

• Light Engine Luminous Output: 90,000 lumens
• Fixture Luminous Output: 46,500 lumens
• Peak Luminous Intensity: 2,600,000 cd
• CCT: 6000 K (+/- 250 K)

OPTICS

• 160 mm front Lens
• 1:7 zoom range - 7.7° - 53°
• High resolution projection system

DYNAMIC EFFECTS

• 0 - 100% continuous dimming and strobe effects
• Choice of four dimming curves
• CMY color mixing
• Color temperature control - 6000-2850 K
• Color wheel with 6 x interchangeable dichroic filters, including Spectral Enhancement Filter
• Rotating gobo wheel 1 includes 5 interchangeable gobos + open
• Rotating gobo wheel 2 includes 5 interchangeable gobos + open
• Gobo animation wheel, indexing, continuous rotation with variable angle
• Frost (fade in)
• 4-facet prism
• Iris
• Zoom
• Focus with auto tracking
• Extended Framing module with individual +/- 30° across entire beam and +/- 83° rotation
• Pan: 540°
• Tilt: 268°
• P3 videomapping of fixture color and/or intensity
• Pre-programmed effects: Two ranges of pre-programmed FX

COOLING AND NOISE

• Low noise cooling system
• User-selectable output vs. sound level control

CONSTRUCTION

• Height (head straight up): 864 mm (34.1 in.)
• Height (maximum): 876 mm (34.5 in.)
• Weight: 44.0 kg (97.0 lbs.)

CONTROL

• DMX-512 in/out
• Ethercon in/out for P3, Art-Net, sACN
• Built in Ethernet switch with fail-safe bypass
