Progressa™ bed system

Introducing the new Progressa® bed system for the ICU

The Progressa® bed system responds to the evolving needs of caregivers, patients and health care facilities. More than just a bed, the Progressa bed system is a therapeutic device that acts as a seamless extension of the health care team.

Patient Mobility

The Progressa bed system provides features and functions that help support early mobility
An intended use of the bed system is to treat or prevent pulmonary or other complications associated with immobility

Patient Repositioning

Available only with the Progressa bed system, StayInPlace™ Technology extends the head section of the frame and surface, in unison, to accommodate the natural elongation of the body as the patient sits up
StayInPlace™ Technology is designed to help address patient migration to the footend of the bed

Platform Scalability

The flexibility of the Progressa bed system platform allows you to configure the bed to your current needs and make upgrades as those needs change

Hillrom

Specification

echnical Specifications
Length 88" (223.5 cm)
Width 40.5" (103 cm)
Highest Position:
Top of Seat Section to Floor 35" (89 cm)
Lowest Position:
Top of Seat Section to Floor 16.5" (41.9 cm)
Standard Caster 6 in" (15.24 cm)
Safe Working Load 650 lbs (295 kgs)
Maximum Patient Weight 500 lbs (227 kgs)
C-Arm Clearance 7-15" (17.8-38.1 cm)
Voltages 100/110/115/120/
127/220/230/240
Cleanability/Infection Control IPX4
Radiolucent Sleep Deck Standard 17.7" x 23"
(45 cm x 58.5 cm)
Place of Manufacture USA
Articulation Specifications
Head 0°-67°
Thigh 0°-30°
Foot 0°-70°
Trendelenburg 13°
Tilt Table Function (Reverse Trendelenburg) -18°
Mattress Details
Prevention Surface
Mattress Width 35" (88.9 cm)
Mattress Length 84" (213 cm)
Mattress Height 7.1" (18.1 cm)
Mattress Weight 31 lbs (14.1 kgs)
Therapy Surface
Mattress Width 35.5" (90.2 cm)
Mattress Length 84" (213 cm)
Mattress Height 8.34" (21.2 cm)
Mattress Weight 45 lbs (20.5 kgs)
Pulmonary Surface
Mattress Width 35.5" (90.2 cm)
Mattress Length 84" (213 cm)
Mattress Height 8.34" (21.2 cm)
Mattress Weight 49 lbs (22.3 kgs)
