Acoustic Double Glazed Glass Swing Door
Acoustic Double Glazed Glass Swing Door
Acoustic Double Glazed Glass Swing Door
Acoustic Double Glazed Glass Swing Door
Acoustic Double Glazed Glass Swing Door
Acoustic Double Glazed Glass Swing Door
Acoustic Double Glazed Glass Swing Door

    Acoustic Double Glazed Glass Swing Door

    Double Glazed Acoustic Swing Doors fit seamlessly into the Solare™ Double Glazed, Elevare™ Stacking Double Glazed High Wall , Movare™ Movable Double Glazed or Transverto™ MonobIock Modular for superior sound resistance and style.

    Tempered, laminated and low iron glazing is compatible with the door, and may be clear, patterned or have a custom graphic. The Double Glazed Acoustic Swing Door fits into straight or curved configurations. A pair of doors is also an option for wider entryways. Our handles, hinges, pivots, and closers are compatible with the Double Glazed Acoustic Swing Door. Available frame finishes include our standard polyester powder coated finish (RAL color choices), Brushed Finish and Stainless Steel Finish. Custom finishes are also available. Besides having an acoustic rating of up to 45 STC.

    Specification
      • Acoustic Performance : Up to 45 STC
      • Glazing: 3/16″ thick glass on each side (1 1/8″ air space between glass panels), custom glass configuration available upon request
      • Available Glazing Types: Clear Tempered, Low Iron, Laminated & LCD Privacy Glass
      • Standard Frame Finishes Available: Standard RAL 9006 and Clear Anodized. Custom Color Powder Coating Available
      • Available Hardware: Free Swing & Self Closing Options, Locking Lever Handle, Standard Lever Handle, 4 1/2″ Hinges, Recessed Floor Closer, Offset Pivots
    Technical specification
    • Unique ref.avanti-acoustic-double-glazed-glass-swing-door
    • Product familyPivot & Hinged Doors
    • Product groupAcoustic Double Glazed
    • TypeObject (single object)
    • Date of publishing2018-12-16
    • Edition number1
    Related
    • Material mainGlass
    • Material secondaryAluminium
    • Designed inUnited States
    Classification
    • BIMobject CategoryDoors - Swing
    • IFC classificationDoor
    • UNSPSC nameWooden doors
    • UNSPSC code30171504
    • Uniclass 2015 CodeEF_25_30
    • Uniclass 2015 DescriptionDoors and windows
    • CSI MasterFormat 2014 Code08 14 00
    • CSI MasterFormat 2014 TitleWood Doors
    • OmniClass Number23-17 11 15
    • OmniClass TitleWood Doors
    • CSI UniFormat II CodeC1020
    • CSI UniFormat II TitleInterior Doors
