BIOLUX Tunable White Downlight Gen 2
BIOLUX Tunable White Downlight Gen 2
BIOLUX Tunable White Downlight Gen 2
BIOLUX Tunable White Downlight Gen 2
BIOLUX Tunable White Downlight Gen 2
BIOLUX Tunable White Downlight Gen 2
BIOLUX Tunable White Downlight Gen 2
BIOLUX Tunable White Downlight Gen 2
BIOLUX Tunable White Downlight Gen 2
BIOLUX Tunable White Downlight Gen 2
    Ledvance

    BIOLUX Tunable White Downlight Gen 2


    BIOLUX HCL DOWNLIGHT DALI
    Product benefits
  • Luminaire suitable for VIVARES ZIGBEE, BIOLUX HCL and other Zigbee 3.0 light controls
  • Individual Tunable White or HCL light through connection to compatible Zigbee 3.0 controls
  • Light quality of CRI 90 supports increased well-being in HCL applications
  • 7 year system guarantee when operated in a BIOLUX HCL or VIVARES ZIGBEE system
  • Compatible with VIVARES CLOUD SERVICE for energy monitoring
  • External Zigbee driver for extended flexibility and easy installation
  • Good glare reduction (UGR ≤ 19)
    • Product features
  • IoT-ready luminaire with Zigbee 3.0 technology
  • Housing material: Aluminum mirror-finished reflector
  • Connector box with push wire terminal for tool-free connection
  • Through-wiring possible
  • Adjustable color temperature via Tunable White: 2,700…6,500 K
  • Very high color rendering index Ra: > 90
    • Areas of application
  • Direct replacement for luminaires with compact fluorescent lamps
  • Offices, conference rooms
  • Nursery and elderly homes
  • Reception areas, foyers and corridors
    • Equipment / Accessories
  • Connector box with 5-pole terminal included
  • External control gear included
  • LEDVANCE BIOLUX app required for commissioning of the BIOLUX HCL system only (available for Android and iOS)
  • LEDVANCE VIVARES app for project planning and required for commissioning of the VIVARES ZIGBEE system only (available for Android and iOS)
    • .

    BIOLUX HCL DOWNLIGHT ZIGBEE GEN 2
    Product benefits
  • Suitable luminaire for VIVARES DALI, VIVARES DALI HCL and other DALI-2 light controls
  • Enables an individual Tunable White lighting solution in combination with compatible DALI-2 lighting controls
  • Light quality of CRI 90 supports increased well-being in HCL applications
  • 7 year system guarantee when operated in a VIVARES DALI system
  • Compatible with VIVARES CLOUD SERVICE for energy monitoring
  • Through-wiring possible with included cable clamp
  • External DALI-2 driver for extended flexibility and easy installation
  • Good glare reduction (UGR ≤ 19)
    • Product features
  • IoT-ready luminaire with DALI-2 technology
  • Adjustable color temperature via Tunable White: 2,700…6,500 K
  • Very high color rendering index Ra: > 90
  • Suitable for central battery emergency installations acc.
  • to EN 60598-2-22
    • Areas of application
  • Direct replacement for luminaires with compact fluorescent lamps
  • Offices, conference rooms
  • Reception areas, foyers and corridors
    • Equipment / Accessories
  • External control gear included
  • Cable clamp for through wiring preinstalled
    • .
    For guarantee see www.ledvance.com/guarantee
    For this product family multiple variants might exist with specific properties!
    Please refer to the specification text where each product url is listed.
    Older generations of a product family can be accessed at our website https://www.ledvance.com.
    You need to use Revit 2021 or higher to use our Revit files.
    Contact: bim@ledvance.com
    Specification

    • Please note that the provided Revit-file can be valid for a product family!
      To access further product information, please follow the attached list of EAN-GTIN numbers.

      Product EAN-GTIN list:

      4099854140310 BIOLUX HCL DL DN150 S 21W TW DALI LEDV
    • Catalog:
      • https://www.ledvance.com/shortlink/4099854140310

      4058075724600 BIOLUX HCL DL DN150 S 20W TW ZB LEDV
    • Catalog:
      • https://www.ledvance.com/shortlink/4058075724600
    Technical specification
    • Unique ref.Biolux-Tunable-White-Downlight
    • Product familyProfessional luminaires
    • Product groupBIOLUX
    • TypeObject (single object)
    • Date of publishing2023-10-31
    • Edition number1
    Links
    Related
    • Material mainAluminium
    • Manufactured inChina
    Classification
    • BIMobject CategoryLighting - Other
    • ETIM CodeEC001744
    • ETIM NameDownlight/spot/floodlight

    Region availability
