    WICSLIDE 150 PS - Slider

    WICSLIDE 150 PS is a hybrid solution because it combines the advantages of a sliding system with the features of a window. The patented central sealing system guarantees optimum water-tightness – up to four times greater than standard sliding doors. Thanks to excellent thermal insulation and watertightness, the WICSLIDE 150 PS offset-sliding system is the innovative solution to meet the challenges of climate change. Specifically developed for a high level of comfort with the secure micro-ventilation system, WICSLIDE 150 PS offers an innovative solution and ensures smooth low-noise operation. The profiles have been extruded from Hydro CIRCAL 75R aluminium – a top quality aluminium alloy composed of at least 75% recycled end-of-life aluminium (post-consumer scrap).

    System tests / CE product passin accordance with EN 14351-1:2006+A2:2016

    Thermal insulation Uw up to 1.0 W/(m²K)
    Air permeability: Class A4
    Watertightness: E1200
    Resistance to wind load: Class 3
    Sound insulation: Rw up to 45 (-2;-5) dB
    Operating forces: Class 1
    Mechanical strength: Class 4
    Durability: Class 3 (20,000 cycles)
    Impact resistance: Class 2


    Specification
    • Technical performance:

      Thermal insulation:
      - Uw up to: 1.0 W/m²K (Ug = 0.7 W/m²K),
      1 sliding sash + fixed light, triple glazing
      w x h = 4,000 x 2,700 mm

      Tightness:
      - Air permeability: Class A4
      - Micro-ventilation: Class A1
      - Watertightness: E1200

      Resistance to wind load: Class 3
      Operating load 1,200 Pa,
      Safety load 1,800 Pa,
      Class 5 up to 3,000 Pa (expected mid 2020)

      Sound insulation:
      - Rw (C;Ctr): 45 (-2;-5) dB -
      Double glazing 50 mm: 88.2 Si / 20 / 66.2 Si

      Operating forces: Class 1

      Burglar resistance RC 2 (expected mid 2020)

    Technical specification
    • Unique ref.WICSLIDE_150_PS
    • Product familySliders
    • Product groupSliding windows
    • TypeObject (single object)
    • Date of publishing2021-01-13
    • Edition number1
    • Height (mm)2700
    • Width (mm)4000
    Related
    • Material mainAluminium
    • Designed inGermany
    • Manufactured inGermany
    • Weight Net (Kg)300
    Classification
    • BIMobject CategoryWindows - Opening Slide
    • UNSPSC nameWindows
    • UNSPSC code301716
