BE WOOD 50 - Operator Chair

4.2(6 reviews)

Spezifikation

Spezifikation

• BACKREST - 14-mm thick plywood, formed and machined to an ergonomic shape. - 25-mm thick block foam with a density of 40 kg/m3 is adhered to the backrest and the fabric or leather is fitted on top. - Height-adjustable lumbar support which can be adjusted 50 mm via a control on the side. - Attached to the seat with a welded metal fixture. SEAT - Made of 12-mm thick beech plywood. 50-mm thick block foam with a density of 35 kg/m3 is adhered to this support and the fabric or leather is fitted on top. The bottom is lined with black fabric. ARMRESTS - Height adjustable with a range of 50 mm and 5 positions. The arms slide on polyamide guides to prevent noise. - The sides of the armrests are lined with a flame-retardant barrier and 12-mm thick block foam with a density of 60 kg/m3 is adhered on top. - The entire assembly is covered with fabric or leather to order. MECHANISM - Self-adjusting mechanism sensitive to the weight of the user. Synchronised backward movement of 18° and forward movement of 6º. 3 adjustment positions and backrest tilt lock. COLUMN - SBS gas piston with a travel of 120 mm to adjust the height of the seat. BASE - Polyamide base. Castors, 60mm in diameter. --- Aluminium base option. --- Castors for hard floor or soft floor option.

Technische Spezifikation

Technische Spezifikation

• Referenznummerbewood504legswood
• ProduktfamilieCHAIRS
• ProduktgruppeWork Chairs
• TypObjekt (Einzelobjekt)
• Veröffentlichungsdatum2014-03-27
• Editionsnummer1
• Höhe (mm)750
• Breite (mm)525
• Tiefe (mm)575

Links

Links

• Produkt urlhttps://www.dynamobel.com/en/productos/be-wood/
• ProductCertificationhttps://www.dynamobel.com/wp-content/uploads/descargas/certificados/es/Be%20Wood-Certificado%20Operativa%20ES.pdf
• Technische Beschreibunghttps://www.dynamobel.com/wp-content/uploads/descargas/ficha_tecnica/en/Be%20Wood-FT%20Operativa%20EN.pdf

Verwandt

Verwandt

• HauptmaterialHolz
• Sekundär MaterialStahl
• Entwickelt inSpanien
• Hergestellt inSpanien

Klassifikation

Klassifikation

• BIMobject KategorieMöbel - Stühle, Hocker und Bänke
• IFCClassificationMöbel
• UNSPSCNameFurniture and Furnishings
• UNSPSCCode56
• Classifications.Uniclass2015CodePr_40_50_12_57
• Classifications.Uniclass2015BeschreibungOffice chairs
• Klassifizierung12 51 00
• Format2014TitelOffice Furniture
• OmniClassNummer23-21 13 25
• OmniClassTitelOffice Equipment
• CSIUniFormatIICodeE2020
• CSIUniFormatIITitleMovable Furnishings
